Intel® OPS Compliant Digital Signage Pluggable Module PC IOPS-Q67/H61
[ Date: 2013-3-13 11:44]
产品特征 |
| |
![](http://files.ieiworld.com/files/news/EN/ProductNews/IOPS-Q67/images/dot_or.gif) |
Complies with Intel® Open Pluggable Specification (OPS) |
![](http://files.ieiworld.com/files/news/EN/ProductNews/IOPS-Q67/images/dot_or.gif) |
High performance Intel® H61/Q67 chipset |
![](http://files.ieiworld.com/files/news/EN/ProductNews/IOPS-Q67/images/dot_or.gif) |
Great resolution |
|
OPS: Up to 1920 x 1200 DisplayPort: Up to 2560 x 1600 |
![](http://files.ieiworld.com/files/news/EN/ProductNews/IOPS-Q67/images/dot_or.gif) |
Intel® HD Graphics with Full HD decoding capability |
![](http://files.ieiworld.com/files/news/EN/ProductNews/IOPS-Q67/images/dot_or.gif) |
Support LAN, USB 2.0, RS-232 | |
![IOPS-H61/Q67](/UploadPic2/2013-3/2013313114415319.jpg) | |
|
Compliant with Intel® Digital Signage Open Pluggable Specification (OPS) |
|
|
Figure 1. Functional Block Diagram |
Compatible Display Model |
![Figure 1. Functional Block Diagram](http://files.ieiworld.com/files/news/EN/ProductNews/IOPS-Q67/images/Block_Diagram.png) |
Display Brand |
Display Model |
NEC |
X461S (46") |
TVS |
DS-42 (42") |
TPV |
DS421OMC (42") |
Philips |
BDL-4245E (42") |
Mitsubishi |
MDT551S (55") |
eJump |
PX420CHN-OPS (42") | | |
|
产品规格 |
|
|
Model Name |
IOPS-H61-C-4GB-R10 |
IOPS-Q67-i5-4GB-R10 |
CPU |
Intel® Celeron® Processor G530 2.4GHz |
Intel® Core™ i5-2390T Processor 2.7GHz |
Memory |
DDR3 SO-DIMM 4GB (4GB *1) |
Graphics |
Intel® HD Graphics |
Video Output |
1 x DisplayPort (external) 1 x JAE connector (OPS compliance) |
Max Output Resolution |
DisplayPort: 2560 x 1600 DVI: 1920 x 1200 |
Audio Output |
1 x 3.5mm line-out |
Storage |
1 x SDHC card slot 1 x mSATA slot (default storage mSATA 32GB) |
LAN |
1 x 10/100/1000 Mbps Ethernet |
USB |
2 x USB 2.0 |
Serial |
1 x RS-232 (RJ45-to-Serial) 1 x RS-232 (OPS) |
Expansion Slot |
1 x mini PCIe half size 1 x mini PCIe full size (default storage mSATA 32GB) |
Intel® AMT Support |
No |
Yes |
Watchdog |
Internal hardware watchdog for error recovery |
Buttons |
Power button Reset to factory default button |
Power |
12V ~ 19V DC |
Demension (W x D x H) (mm) |
200 x 148 x 30 |
Mounting |
OPS slot |
Operating Temperature |
0°C to 40°C |
|
|
Dimensions (Unit: mm) |
|
|
![](http://files.ieiworld.com/files/news/EN/ProductNews/IOPS-Q67/images/IOPS_Dim.png) |
|
包装清单 |
|
|
Item |
Q'ty |
描述 |
Utility CD |
1 |
Drivers and user manual |
One Key Recovery CD |
1 |
|
RS-232 cable (RJ-45 to DB-9) |
1 |
| |
|
Options |
|
|
Item |
P/N |
描述 |
OS: Win 7 Embedded |
IOPS-Q67-WES7E-R10 |
OS Image with Windows® Embedded Standard 7 E, for IOPS-Q67/H61 series | |
|
订购信息 |
|
|
产品名称 |
描述 |
IOPS-H61-C-4GB-R10 |
OPS Module PC, Intel® Celeron G530 2.4GHz, TDP 65W, 4GB DDR3 SO-DIMM pre-installed, mSATA 32GB, DisplayPort, Intel® GbE, JAE 80-pin connector, USB 2.0, serial port, SDHC card slot, HD Audio, 0°C~45°C, R10 |
![](http://files.ieiworld.com/files/news/EN/ProductNews/IOPS-Q67/images/Available_May.png) IOPS-Q67-i5-4GB-R10 |
OPS Module PC, Intel® i5-2390T 2.7GHz, TDP 65W, 4GB DDR3 SO-DIMM pre-installed, mSATA 32GB, DisplayPort, Intel® GbE, JAE 80-pin connector, USB 2.0, serial port, SDHC card slot, HD Audio, 0°C~45°C, R10 | |
