> 产品 > EPIC NANO系列主板 > NANO-ULT3| ● EPIC SBC with 6th generation Intel® ULT proccessor supports dual-channel DDR4 SODIMMs |
|
● Triple independent display support
|
|
● Easy assembly heat spreader for thermal
management
|
|
● Full-size PCIe Mini slot with SIM sockets
for 3G/LTE expansion
|
|
● COM, USB 3.0, SATA 6Gb/s, mSATA, eMMC 5.0
and audio support
|
|
● IEI One Key Recovery solution allows you to
create rapid OS backup and recovery
|
产品规格
|
Display
|
Triple independent display |
| 2 x HDMI (up to 4096x2160@24Hz) | |
| 1 x 18/24-bit dual-channel LVDS by CH7511B DP to LVDS converter (up to 1920x1200@60Hz) | |
|
CPU
|
6th generation Intel® mobile ULT on-board SoC |
| Intel® Core™ i7-6600U (up to 3.4GHz, dual-core, 4MB cache, TDP=15W) | |
| Intel® Core™ i5-6300U (up to 3.0GHz, dual-core, 3MB cache, TDP=15W) | |
| Intel® Core™ i3-6100U (up to 2.3GHz, dual-core, 3MB cache, TDP=15W) | |
| Intel® Celeron® processor 3955U (up to 2.0GHz, dual-core, 2MB cache, TDP=15W) | |
|
Memory Max.
|
Two 260-pin 2133/1866 MHz dual-channel DDR4 non-ECC unbuffered SO-DIMMs (system max. |
| 32 GB) | |
|
Ethernet
|
LAN1: Intel® I219-LM PHY with Intel® AMT 11.0 supported |
| LAN2: Intel® I211-AT PCIe GbE controller | |
|
Digital I/O
|
1 x 8-bit digital I/O (2x5 pin) |
|
Audio
|
Realtek ALC662 HD codec |
| 1 x Analog audio (2x5 pin) | |
|
Power consumption
|
12V@2.48A (Intel® Core™ i3-6100U CPU with two 8 GB memory) |
|
Operating Temperature
|
-20°C ~ 60°C |
|
Humidity
|
5% ~ 95%, non-condensing |
|
iRIS
|
- |
|
Storage
|
1 x 8 GB eMMC (optional) |
| 2 x SATA 6G/s with 5V SATA power connector (RAID 0,1) | |
|
Expansion Slots
|
1 x Full-size PCIe Mini card slot (with SIM holder & mSATA support) |
| 1 x Half-size PCIe Mini card slot | |
|
Watchdog Timer
|
Software programmable supports 1~255 sec. system reset |
|
CPU Cooler
|
N/A |
|
I/O Interface
|
3 x Internal USB 2.0 |
| 4 x USB 3.0 |
订购信息
| NANO-ULT3-i7-R10 | EPIC SBC supports Intel® 14nm 6th Generation Mobile Core™ i7-6600U (15W) on-board Processor (ULT) with HDMI/LVDS/iDP, Dual PCIe GbE, USB 3.0, Dual PCIe Mini, SATA 6Gb/s, mSATA , COM, Audio and RoHS |
| NANO-ULT3-C-R10 | EPIC SBC supports Intel® 14nm 6th Generation Mobile Celeron® 3955U (15W) on-board Processor (ULT) with HDMI/LVDS/iDP, Dual PCIe GbE, USB 3.0, Dual PCIe Mini, SATA 6Gb/s, mSATA , COM, Audio and RoHS |
| NANO-ULT3-i3-R10 | EPIC SBC supports Intel® 14nm 6th Generation Mobile Core™ i3-6100U (15W) on-board Processor (ULT) with HDMI/LVDS/iDP, Dual PCIe GbE, USB 3.0, Dual PCIe Mini, SATA 6Gb/s, mSATA , COM, Audio and RoHS |
| NANO-ULT3-i5-R10 | EPIC SBC supports Intel® 14nm 6th Generation Mobile Core™ i5-6300U (15W) on-board Processor (ULT) with HDMI/LVDS/iDP, Dual PCIe GbE, USB 3.0, Dual PCIe Mini, SATA 6Gb/s, mSATA , COM, Audio and RoHS |
