 产品规格 | | | | CPU | LGA1155 socket 支持 Intel® Core™ i7/i5/i3/Pentium®/Celeron 处理器 | | 芯片组 | Intel® H61 | | BIOS | UEFI | | 内存 | 2 x 240-pin 1333/1066MHz 双通道 unbuffered DDR3 SDRAM DIMM (系统最大支持16GB) | | 以太网 | Dual Realtek RTL8111E PCIe GbE controllers, LAN1支持 ASF2.0 | | I/O接口 | 5 x RS-232
1 x RS-422/485
1 x LPT
4 x SATA 3Gb/s
1 x PS/2 KB/MS
10 x USB 2.0 (4 x 后面板 IO, 6x pin header) | | 数字I/O | 8-bit 可编程 I/O | | Super I/O | Fintek F81866 | | TPM | 1 x 20-pin header | | SMBus | 1 x 4-pin wafer | | 音频 | Realtek ALC662 HD 音频编码 (音频输入,音频输出,麦克风) | | 显示接口 | VGA 集成于Intel® H61
DVI-D 集成于Intel® H61 | | 扩展槽 | 1 x PCIe x16 插槽
2 x PCIe x1 插槽
4 x PCI 插槽 | | 看门狗定时器 | 软件可编程支持 1~255 sec.系统复位 | | 电源 | AT / ATX 电源 | | 风扇 | 1 x 4-pin CPU 风扇接口
2 x 3-pin 系统风扇接口 | | 功耗 | 3.3V@1.27A, 5V@3.87A , 12V@0.54A, Vcore@7.67A, 5VSb@0.15A (Intel® Core™ i7-2600K 3.40GHz CPU 支持 2 个 1333MHz 2GB DDR3 内存) | | 视频引擎 | Intel® HD Graphics 2000/3000 (基于 CPU 类型)
支持 DX10.1 和 OpenGL3.0
Full MPEG2, VC1, AVC Decode | | 工作温度 | -10°C ~ 60°C | | 相对湿度 | 5% ~95%,无冷凝 | | 尺寸 | 244mm x 305mm | | 重量 | GW:1200g, NW: 700g | | Front Panel | 1 x 前面板接口(电源 LED, HDD LED, 扬声器,电源按钮,复位按钮) | | I2C | 1 x 4-pin wafer |
|
|
| 订购信息 | | | | 产品名称 | 描述 | | IMBA-H610-R10 | ATX Motherboard supports LGA1155 Intel® Core™ i7/i5/i3/Pentium®/Celeron® CPU with Intel® H61, DDR3, VGA/DVI-D, Dual Realtek PCIe GbE, USB 2.0, SATA 3Gb/s, HD Audio and RoHS | | 19800-003100-100-RS | Dual-port USB cable with bracket | | 32200-074800-RS | RS-422/485 cable, 200mm | | 19800-000051-RS | RS-232 cable, 230mm | | 32102-000100-200-RS | SATA power cable | | 19800-000049-RS | LPT cable | | TPM-IN01-R11 | 20-pin Infineon TPM module, software management tool, firmware V3.17 | | CPU-DT-i5-2500T | Intel® Core™ i5-2500T processor, LGA1155, Quad core 2.3GHz, 6M Cache, 45W, compatible with CF-1156C-RS CPU cooler | | CPU-DT-i5-2390T | Intel® Core™ i5-2390T processor, LGA1155, Dual core 2.7GHz, 3M Cache, 35W, AMT, compatible with CF-1156C-RS CPU cooler | | CPU-DT-i3-2100T | Intel® Core™ i3-2100T processor, LGA1155, Dual core 2.5GHz, 3M Cache, 35W, compatible with CF-1156C-RS CPU cooler | | CPU-DT-P-G620T | Intel® Pentium G620T processor, LGA1155, Dual core 2.2GHz, 3M Cache, 35W, compatible with CF-1156C-RS CPU cooler | | CPU-DT-C-G440 | Intel® Celeron G440 processor, LGA1155, Single core 1.6GHz, 1M Cache, 35W, compatible with CF-1156C-RS CPU cooler | | CF-1156A-RS | High-performance LGA1155/LGA1156 cooler kit, 1U chassis compatible, 73W | | CF-1156B-RS | High-performance LGA1155/LGA1156 cooler kit, 95W | | CF-1156C-RS | LGA1155/LGA1156 cooler kit, 1U chassis compatible, 45W | | CF-1156D-RS | LGA1155/LGA1156 cooler kit, 1U chassis compatible, 65W |
|
|
