> 产品 > ETX 模块 > ICE-ULT3| ● Intel® Skylake ULT Processors supported |
|
● Intel® HD Graphics technology integrates
high-performance graphics and media processing
|
|
● Two 260-pin 2133/1867 MHz Dual-Channel DDR4
SDRAM Unbuffered DIMM supported (system max. 32GB)
|
|
● 18/24-bit dual-channel LVDS, analog CRT,
DDI supported
|
|
● IEI One Key Recovery solution allows you to
create rapid OS backup and recovery
|
|
● Support Intel® AMT 11.0
|
产品规格
|
put
|
1 x DDI: DisplayPort/HDMI/DVI (up to 3840x2160@60Hz) |
| 1 x DDI: DisplayPort/HDMI/DVI (up to 3840x2160@60Hz) | |
| (Option with 1 x CRT via CH7517) (up to 1920x1200@60Hz) | |
| 1 x DDI: Embedded DP (up to 3840x2160@60Hz) | |
| (Option with 1 x Dual Channel LVDS 18/24 bit via CH7511B) (up to 1920x1200@60Hz) | |
|
CPU
|
6th generation Intel® mobile ULT on-board SoC |
| Intel® Core™ i7-6600U (up to 3.4GHz, dual-core, 4MB cache, TDP=15W) | |
| Intel® Core™ i5-6300U (up to 3.0GHz, dual-core, 3MB cache, TDP=15W) | |
| Intel® Core™ i3-6100U (up to 2.3GHz, dual-core, 3MB cache, TDP=15W) | |
| Intel® Celeron® processor 3955U (up to 2.0GHz, dual-core, 2MB cache, TDP=15W) | |
| Intel® Celeron® processor 3855U (up to 1.6GHz, dual-core, 2MB cache, TDP=15W) | |
|
Memory Max.
|
Two 260-pin 2133/1866 MHz dual-channel DDR4 non-ECC unbuffered SO-DIMMs |
| support up to 32GB | |
|
Ethernet
|
Intel® Clarkville-V I219LM Support Intel® AMT 11.0 |
|
Expansion
|
1 x PCIe x1 signal to base board (Via PCIe x16 channel) |
| 8 x PCIe x1 signal to base board | |
|
Power consumption
|
+12V@2.57A, 5VSB@0.04A, 5V@0.02A |
| (Intel® Core™ i7-6600U with two 8GB 2400 MHz DDR4 memory) | |
|
Operating Temperature
|
-20°C ~ 65°C |
|
Humidity
|
5% ~ 95%, non-condensing |
|
Dimensions
|
95 mm x 95 mm |
|
Weight
|
GW: 600g / NW: 250g |
|
I/O Interface
|
4 x Internal USB 2.0 |
| 4 x Internal USB 3.0 | |
| 2 x Internal RS-232 | |
| 2 x SATA 6Gb/s |
订购信息
| ICE-ULT3-C-R10 | COM Express Compact size Type 6 Module, Intel® Celeron® 3955U (15W) ULT Processor,DDR4, VGA, LVDS, DDI, GbE, SATAIII, USB 3.0 and HD Audio, RoHS |
| ICE-ULT3-i5-R10 | COM Express Compact size Type 6 Module, 6th Generation Intel® Core™ i5-6300U (15W) ULT Processor,DDR4, VGA, LVDS, DDI, GbE, SATAIII, USB 3.0 and HD Audio, RoHS |
| ICE-ULT3-i3-R10 | COM Express Compact size Type 6 Module, 6th Generation Intel® Core™ i3-6100U (15W) ULT Processor,DDR4, VGA, LVDS, DDI, GbE, SATAIII, USB 3.0 and HD Audio, RoHS |
| ICE-ULT3-i7-R10 | COM Express Compact size Type 6 Module, 6th Generation Intel® Core™ i7-6600U (15W) ULT Processor,DDR4, VGA, LVDS, DDI, GbE, SATAIII, USB 3.0 and HD Audio, RoHS |
