●Intel® Xeon® W family processor supported |
●6 x PCIe Slot, up to 4 dual width GPU cards
|
●Water cooling system on CPU
|
●Support two U.2 SSD
|
●Support one M.2 SSD M-key slot ( NVMe PCIe
3.0 x4 )
|
●Support 10GbE network
|
●IPMI remote management
|
产品规格
Display Output
| 1 x VGA |
Ethernet
| 2 x LAN (1 x 1GbE RJ45 combo LAN ports / IPMI; 1 x 10GbE RJ45 LAN port) |
I/O Interface
| 1 x External RS-232 |
1 x Internal RS-232 | |
2 x External USB 2.0 | |
4 x External USB 3.0 | |
1 x Internal USB3.0 | |
1 x Internal USB2.0 | |
Expansion
| 4 x PCIe x 8 (PCIe 3.0) |
2 x PCIe x 4 (PCIe 3.0) | |
Rack Height
| 4U |
Dimensions (LxWxH) (mm)
| 176.15 x 480.94 x 644 |
Storage
| 8 x 2.5” SSD/HDD Bay |
12 x 3.5” HDD Bay | |
20 x SATA | |
1 x M.2(NGFF) | |
2 x U.2 | |
CPU
| Intel® Xeon® W Family Processors |
Chipset
| Intel® C422 |
Memory Max.
| Memory expandable up to: 256 GB (64 GB x 4) |
Cooling method / System Fan
| 2 x Smart Fan (12cm 12V DC) |
GRAND-C422-20D-S1A1-R10 | 20-bay(3.5" x12, 2.5" x 8) 4U Rackmount, Intel® Xeon® W-2123 with C422 chipset, 32G DDR4 w/ECC, 6 x PCIe expansion slot, and 1600W redundant PSU, RoHS |
GRAND-C422-20D-S1B2-R10 | 20-bay(3.5" x12, 2.5" x 8) 4U Rackmount, Intel® Xeon® W-2133 with C422 chipset, 64G DDR4 w/ECC, 6 x PCIe expansion slot, and 1600W redundant PSU, RoHS |
GRAND-C422-20D-S1C3-R10 | 20-bay(3.5" x12, 2.5" x 8) 4U Rackmount, Intel® Xeon® W-2145 with C422 chipset, 128G DDR4 w/ECC, 6 x PCIe expansion slot, and 1600W redundant PSU, RoHS |
GRAND-C422-20D-S1D3-R10 | 20-bay(3.5" x12, 2.5" x 8) 4U Rackmount, Intel® Xeon® W-2155 with C422 chipset, 128G DDR4 w/ECC, 6 x PCIe expansion slot, and 1600W redundant PSU, RoHS |
GRAND-C422-20D-S1E4-R10 | 20-bay(3.5" x12, 2.5" x 8) 4U Rackmount, Intel® Xeon® W-2195 with C422 chipset, 256G DDR4 w/ECC, 6 x PCIe expansion slot, and 1600W redundant PSU, RoHS |
